Type: PAH 32 CCW (Counter Clock-wise Rotation)Flow at 1500 rpm: 45.3 l/minMaximum Shaft Speed: 1800Maximum Pressure: 160 BarPorts / Connections (In, Out): G1 1/4, G3/4Housing Material: AISI 304 Stainless Steel
Monday-Friday 8:30am – 5pm
Customer Support
Established 25 years
Family run business
Fast Delivery
many items held in stock
Trade Counter
Monday-Friday 8:30am – 5pm
180B0061 Danfoss PAH 32 CCW Tap Water Pump
High-pressure pump range based on the axial piston principle (5–9 pistons) enabling a very light and compact design. Very low pulsation and airborne noise.
PAH 2/4/6.3, PAH 10/12.5, PAH 20/25/32 and PAH 50/63/70/80/100 are pumps designed to supply water flow under high pressure. The pumps are based on the axial piston principle enabling a very light and compact design.
The pumps are designed so that lubrication of the moving parts in the pumps is provided by the water itself. No oil lubrication is thus required.
All parts included in the pumps are designed to provide long service life, i.e. long service life with a constantly high efficiency and minimum of service required.
The pumps are fixed displacement pumps where the flow is proportional to the number of revolutions of the input shaft and the pump displacement.
Weight: 16.0 kg
Coming SoonNo
Country of Origin(EU)
Discount CouponNo
Export Commodity Code8413 5061
featuredNo
International Article Number (EAN)NA
Product Linespah
Remove Compare LinkNo
Stock StatusUsually Ships in 4 to 6 Weeks
Timed DeliveriesPLEASE DO NOT SELECT TIMED DELIVERIES FOR THIS PRODUCT – CALL +44 (0)1772 699 999 If Urgent
Use in Deepzoom GalleryNo
